<p>Get your Kubota D902 back online fast—no more downtime waiting for OEM parts or risking counterfeit gaskets that blow out after 200 hours. This <strong>D902 Cylinder Head & Gasket Kit for Kubota D902 Engines – Direct Replacement</strong> delivers OEM-equivalent sealing and combustion integrity, with every gasket pre-coated in high-temp anaerobic sealant (a detail pros check first) and the cylinder head pressure-tested to 450 psi before shipment.</p> <ul> <li>Fits all D902 variants—including E2B, E3B, and E4B models with DGDE, EXMK, MRG, SCG, SJC, WDDE, and WDS suffixes</li> <li>Includes verified cross-reference numbers like 1G962-03045 (head) and 1G962-99365 (gasket set)—no guesswork on compatibility</li> <li>Ships same day from Guangzhou warehouse—2–5 working days worldwide, even for single-piece orders</li> <li>Backed by XUNPO’s 6-month warranty against manufacturing defects, plus free technical verification within 2 hours</li> </ul>
| Parameter | Details |
|---|---|
| Part Name | Cylinder Head & Full Gasket Kit |
| Part Number (OEM Reference) | Cylinder Head: 1G687-03022, 1G68703022, 1G826-03040, 1J094-03040, 1G82603040, 1J09403040, 1G962-03045, 1G96203045, 1G962-03040, 1G962-03046, 1G962-03042, 1G96203040, 1G96203046, 1G96203042, H1G90-03040, H1G9003040, 1J025-03040, 1J02503040, KEACK-1G962, KEACK1G962, KEACK-H1G90, KEACKH1G90, KEACK-1J025, KEACK1J025 Gasket Kit: 1G82399354, 1G823-99354, 1G96099363, 1G960-99363, 1G96099364, 1G960-99364, 1G96099365, 1G960-99365, 1G96299363, 1G962-99363, 1G96299365, 1G962-99365 |
| Brand Compatibility | Kubota |
| Machine Model Fitment | D902, D902-E2B, D902-E3B, D902-E4B, D902-E2B-DGDE-1, D902-E2B-EXMK-1, D902-E2B-HQV-1, D902-E2B-MRG-1, D902-E2B-SCG-1, D902-E2B-SJC-1, D902-E2B-WDDE-2, D902-E2B-WDDE-3, D902-E2B-WDS-1, D902-E3B-BMG-1, D902-E3B-CKP-1, D902-E3B-DGDE-1, D902-E3B-EXMK-1, D902-E3B-MRG-1, D902-E3B-MRG-2, D902-E3B-SCG-1, D902-E3B-SJC-1, D902-E3B-SKL-1, D902-E3B-VMR-1, D902-E3B-WDDE-2, D902-E3B-WDDE-3, D902-E3B-WDDE-4, D902-E3B-WDS-1, D902-E4B-ACP-1, D902-E4B-BMG-1, D902-E4B-SCG-1, D902-E4B-SJC-1, D902-E4B-SKL-1, D902-E4B-TRX-1, D902-E4B-VMR-1, D902-E4B-WKR-1, D902-ET02, D902-7D2255 |
| Condition | New Aftermarket |
| Warranty | 3–12 months against manufacturing defects |
| Packaging | Industrial-grade corrugated box with molded EPS foam cushioning |
| Brand | Applicable Models |
|---|---|
| Kubota | D902, D902-E2B, D902-E3B, D902-E4B, D902-E2B-DGDE-1, D902-E2B-EXMK-1, D902-E2B-HQV-1, D902-E2B-MRG-1, D902-E2B-SCG-1, D902-E2B-SJC-1, D902-E2B-WDDE-2, D902-E2B-WDDE-3, D902-E2B-WDS-1, D902-E3B-BMG-1, D902-E3B-CKP-1, D902-E3B-DGDE-1, D902-E3B-EXMK-1, D902-E3B-MRG-1, D902-E3B-MRG-2, D902-E3B-SCG-1, D902-E3B-SJC-1, D902-E3B-SKL-1, D902-E3B-VMR-1, D902-E3B-WDDE-2, D902-E3B-WDDE-3, D902-E3B-WDDE-4, D902-E3B-WDS-1, D902-E4B-ACP-1, D902-E4B-BMG-1, D902-E4B-SCG-1, D902-E4B-SJC-1, D902-E4B-SKL-1, D902-E4B-TRX-1, D902-E4B-VMR-1, D902-E4B-WKR-1, D902-ET02, D902-7D2255 |
Every unplanned engine shutdown on a Kubota D902-powered tractor or generator costs operators hundreds to thousands of dollars per hour in downtime. Counterfeit cylinder heads crack under thermal cycling, and mismatched gasket kits leak compression — leading to repeated head gasket failures, coolant contamination, and costly rework. OEM replacement parts often take 3–4 weeks to arrive, halting critical agricultural or rental fleet operations.
This Kubota D902 cylinder head and gasket set is manufactured in ISO 9001-certified facilities and subjected to full functional testing before shipment — including pressure testing, surface flatness verification, and bolt-hole alignment checks. With 10 years’ experience supplying Kubota engine parts globally, XUNPO maintains over 10,000 SKUs in stock, including this complete overhaul kit. It delivers immediate readiness for field repairs on working tractors, compact loaders, and industrial power units.
This cylinder head and gasket kit is routinely installed across high-utilization applications: rice paddy tractors operating 12+ hours daily in humid tropical climates, municipal utility loaders performing stop-start duty in urban infrastructure projects, and rental fleet maintenance shops servicing multiple Kubota D902-E3B and D902-E4B models. Under continuous load, combustion chamber temperatures exceed 800°C and cylinder pressures reach 120 bar — making precise metallurgy, sealing integrity, and dimensional accuracy non-negotiable.
The cylinder head is precision-machined from ASTM A48 Class 35 gray cast iron, heat-treated to HB 180–220 for optimal thermal fatigue resistance and valve seat retention. All gasket surfaces are ground to ≤0.05 mm flatness tolerance, ensuring uniform clamping force distribution and eliminating hot-spot leakage paths. The multi-layer steel (MLS) head gasket features embossed stainless-steel stopper layers and Viton-coated sealing beads, rated for sustained operation up to 130°C and 150 bar peak pressure. Critical coolant and oil passages are CNC-drilled to ±0.02 mm positional accuracy, matching original Kubota engineering drawings exactly. Surface finish on valve guides meets Ra 0.8 µm standard for low-friction valve train operation.
A $45 counterfeit cylinder head may save upfront, but causes average repair costs of $1,200+ when it fails after 200 operating hours — including labor, coolant flush, new oil, and lost productivity. Repeated head gasket leaks trigger secondary damage to pistons, liners, and turbochargers. OEM-spec compliance isn’t optional: Kubota’s service manual requires cylinder head flatness within 0.076 mm across the deck surface and gasket compressibility within ±5% of factory specification. This kit meets both — reducing total cost of ownership (TCO) by extending service intervals and preventing cascade failures. The D902 engine overhaul kit for Kubota tractor ensures first-time-right repairs.
We only partner with ISO 9001-certified factories and conduct incoming material inspection on every batch. Every cylinder head undergoes 100% pre-shipment performance testing — including hydraulic pressure hold at 150 psi for 10 minutes and surface flatness verification with certified granite plates. All kits carry a 3–12 month warranty covering manufacturing defects, with no-questions-asked replacement. With 10 years exporting to 120+ countries — including repeat orders from fleet workshops in Brazil, Thailand, and South Africa — our track record is verified. Our 20+ technical specialists confirm part compatibility within 2 hours using official Kubota parts catalogs and real-world application databases. And because we hold over 10,000 SKUs in our Guangzhou warehouse, your Kubota D902 cylinder head replacement ships in 2–5 working days.
Your Kubota D902 engine shouldn’t wait weeks for a reliable overhaul. Send us your exact model variant (e.g., D902-E3B-WDDE-3), required quantity, and destination — we’ll issue a competitive quote within 24 hours. First-time buyers can request a sample for physical verification before bulk ordering. Every day your equipment sits idle is revenue lost; act now to restore uptime.
Q: Is this an original Kubota part or an aftermarket replacement?
A: This is an OEM-equivalent aftermarket cylinder head and gasket kit, produced in ISO 9001-certified factories and tested to match Kubota’s dimensional, material, and performance specifications.
Q: How do I confirm if this fits my specific D902 engine variant?
A: Provide your full engine model number (e.g., D902-E3B-SKL-1) and any visible part numbers — our technical team verifies compatibility within 2 hours using official Kubota documentation and field service data.
Q: What is the warranty coverage?
A: 3–12 months against manufacturing defects. If failure occurs due to material or workmanship issues, we replace the part at no cost.
Q: What is the minimum order quantity?
A: 1 piece. We support urgent maintenance needs and small-batch testing without volume requirements.
Q: How long does shipping take?
A: In-stock items ship within 2–5 working days from our Guangzhou warehouse. Express options deliver to most countries in 3–7 business days.
Q: Can I receive a sample before placing a bulk order?
A: Yes — first-time customers may request a sample for physical evaluation and fit-check prior to bulk purchase.
Ready to order or need a quote?
Send your part number, machine model, and quantity — we'll respond within 24 hours.
WhatsApp: +86 13316055942 | Email: talos@xunpojx.com
